Specifications
Analog inputs & output; XLR (balanced)
Maximum input & output gain
32.5 dBu
Input impedance
20 kΩ
Output impedance
75 Ω
Common mode rejection
-82 dBu
Frequency range (-3 dB)
4 Hz – 300 kHz
Crosstalk (1 kHz)
-108 dBu
THD (0 dBu, 1 kHz)
0.000992 %
Noise (A-weighted)
-102.5 dBu
Dynamic range
135 dB
Digital Inputs, DAC768
AES/EBU (XLR), PCM sample rates
44.1/48/88.2/96/176.4/192 kHz
Coaxial SPDIF (Cinch), PCM sample rates
44.1/48/88.2/96/176.4/192 kHz
Optisch SPDIF (Toslink F06), PCM sample rates
44.1/48/88.2/96/with Glass fibre <1 m: 176.4/192 kHz
USB (B), PCM sample rates
44.1/48/88.2/96/176.4/192/352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP), sample rates
2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz
0 dBfs calibrated to
15 dBu
Internal Linear Power Supply with Shielded Toroidal Transformer
Operating voltage for analog audio
+/- 60 V
Operating voltage for relays and LEDs
+ 12 V
Mains Power Supply
Mains voltage (selectable, see fuse chamber)
230 V AC / 50; 115 V AC / 60 Hz
Fuse for 230 V
T 500 mA
Fuse for 115 V
T 1 A
Power consumption
max. 40 VA
Stand-by power consumption
< 0,3 W
Dimensions & Weight
W x H x D (width x height x depth)
482 x 44 x 300 mm
19 x 1.73 x 11.8 inch
Unit weight
4.55 kg
10 lbs
Shipping weight (incl. packaging)
6.7 kg
14.77 lbs
Reference: 0 dBu = 0,775 V. All specifications are subject to change without notice.
